One scope to rule them all. From dark-timber whitetails, to executing precision long-range shots on an open-country mule deer, and everything in between - there’s the lightweight, second focal plane Razor HD LHT. Stunning, High Definition optical system delivers a crystal-clear sight picture with tack-sharp resolution. Turn every second of legal shooting light into opportunity. Take to the field with confidence knowing you’ve sacrificed nothing with the Razor HD LHT.

SKU	RZR-31501
Magnification	3 – 15
Objective Lens Diameter	42 mm
Eye Relief	3.8 inches
Field of View	35.3-7.0 ft/100 yards
Tube Size	30 mm
Turret Style	Locking/Zero Stop
Windage Turret Style	Capped
Adjustment Graduation	.25 MOA
Travel per Rotation	15 MOA
Max Elevation Adjustment	80 MOA
Max Windage Adjustment	80 MOA
Parallax Setting	20 yards to infinity
Length	13.3 inches
Weight	19.1 oz

• Sunshade
• Lens Covers
• Lens Cloth
• CR2032 battery

Lengths
L1	L2	L3	L4	L5	L6
13.3	2.6	2.0	6.2	3.7	3.4

Heights
H1	H2
2.0	1.7

Dimensions measured in inches.

OPTICAL FEATURES
HD Optical System	Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration and provide outstanding color fidelity, edge-to-edge sharpness and light transmission.
XRPlus Fully Multi-Coated	Premium proprietary coatings deliver the highest level of light transmission with multiple anti-reflective coatings on all air-to-glass surfaces for maximum brightness.
APO System	Index-matched lenses correct color across the entire visual spectrum.
Optically Indexed Lenses	Deliver optimum image sharpness and brightness with true reticle use for full ranging and holdover from edge to edge because of computer-controlled alignment during construction.
Second Focal Plane Reticle	Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
Illuminated Center Dot	Daylight bright illuminated center dot provides a precise point-of-aim in all lighting conditions.

CONSTRUCTION FEATURES
Tube Size	30 mm diameter provides maximized internal adjustment and strength.
Single-Piece Tube	Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
Aircraft-Grade Aluminum	Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
ArmorTek	Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
Waterproof	O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
Shockproof	Rugged construction withstands recoil and impact.
Fogproof	Argon gas purging prevents internal fogging over a wide range of temperatures.
Locking Elevation Turret	Integrated locking mechanism prevents accidental adjustments. Elevation turret provides fast, accurate, easily read elevation adjustments. Patent pending.
Large Diameter Capped Windage Turret	Provide fast, accurate and easily read windage adjustments. Cap provides external protection for windage turret.

CONVENIENCE FEATURES
RevStop™ Zero System	Patented streamlined design offers an easy to set, rock-solid return to zero after turret adjustments.
